Maintenance Manual SP 40
Rev. 005
59
Chapter 3
Operabilty and Configuration
Setup Parameter Values Description
PROTOCOL EPSON 570, IBM X24E*, X24E
AGM, IBM 2390,
OLI. PR40+, OLI. PR2,
OLI. PR2845, IBM 4722, IBM 9068
Defines the printer protocol.
FONT Draft*, Courier, OCR-B, Gothic,
Prestige, Present, OCR-A, Script,
Boldface
Selects the font.
DOWNLINE LOADING Disable, enable* Sets or not the capability of soft font loading in 4722, 9068 protocols.
HORIZONTAL PITCH 10 cpi*, 12 cpi, 15 cpi,
16.6 cpi, 17.1 cpi, 20 cpi
Selects the character spacing in characters per inch (cpi).
VERTICAL PITCH 5 lpi, 6 lpi*, 8 lpi Selects the line spacing in lines per inch (lpi).
LOCK no lock*, font, hor. pitch,
font+hor.pitch
The following selections made via operator panel may be locked: font,
horizontal pitch (hor.pitch), or both the font and horizontal pitch (font+hor.
pitch). The locked settings cannot be changed via software commands.
FORM LENGTH # lines, A4*, letter, A5, legal Sets the page length in number of lines or standard formats A4, Letter, A5 or
Legal. If you select # lines, you must indicate the number of lines you want to
set. The values range between 1 and 255. To set the values combine the
numbers considering that the first line corresponds to the hundreds, the
second line to the tens and the third line to the units. Default is 70.
LEFT MARGIN # You have to indicate the number of chars you want to set. The values range
between 0 and 90. To set the values combine the numbers considering that
the first line corresponds to the the tens and the second line to the units.
Default is 0.
RIGHT MARGIN # You have to indicate the number of chars you want to set. The values range
between 0 and 190. To set the values combine the numbers considering that
the first line corresponds to the the tens and the second line to the units.
Default is 93.
TOP MARGIN # You have to indicate the number of lines you want to set. The values range
between 0 and 90. To set the values combine the numbers considering that
the first line corresponds to the the tens and the second line to the units.
Default is 0.
BOTTOM MARGIN # You have to indicate the number of lines you want to set. The values range
between 0 and 90. To set the values combine the numbers considering that
the first line corresponds to the the tens and the second line to the units.
Default is 0.
IBM C-SET IBM set 1*, IBM set 2 Selects the IBM character set.
IBM COMPRESS 17.1 cpi*, 20 cpi Selects the pitch for the compressed mode printing in IBM emulation.
EPSON C-SET Italic, graphic* Selects italic or graphic Epson character set.
NATION C-SET USA*, FRANCE, GERMANY,
ENGLAND, DENMARK1, SWEDEN,
ITALY, SPAIN1, JAPAN,
NORWAY, DENMARK2, SPAIN2,
LATIN A1
Selects the national character sets.
Table 3.4 - Program 1 (Program 2) Form Parameters description
