Maintenance Manual SP 40
Rev. 005
50
Chapter 3
Operabilty and Configuration
3.2.2 Function Keys
KEY
NORMAL MODE SETUP MODE SPECIAL MODE
STATION1
Pressing this key, when the printer is offline,
or when the printer is online and no print
data are in the buffer, the printer ejects the
paper, if inserted (EJECT function). In the
Olivetti emulation, the EJECT function may
be performed only if the printer is offline.
When using the IBM 4722, IBM 9068 and the
Olivetti protocols in two operators (“booking”)
mode, the application software determines
the function of this key.
When the Printer is in the
Printer Setup mode, pressing
this key the operator selects
the Configuration Page to be
printed. See ” Printer Setup "
later in this manual.
Pressed while powering on
the printer on with ON LINE
selects the T&D Mode.
See chapter 5 in this manual.
STATION2
When the printer is offline or when the printer
is online and no print data are in the buffer,
pressing this key, the printer toggles
between Letter Quality and Draft printing
mode.
When using the IBM 4722, IBM 9068 and the
Olivetti protocols in two operators (“booking”)
mode, the application software determines
the function of these keys.
When the Printer is in the
Printer Setup mode, pressing
this key the Configuration
Page selected with the
STATION1 key will be printed.
See “ Printer Setup ” later in
this manual.
If this key is pressed, while
powering on the printer, the
hexadecimal printing is
selected.
ON LINE
Toggles the printer between online and
offline status.
If pressed in the Printer
Setup mode, the printer
prints the Self Test Page.
See “ Printer Setup " later in
this manual.
Pressed while powering on,
selects the Printer Setup
Mode. See ” Printer Setup "
later in this manual.
Pressed while powering on
with STATION1 selects the
T&D Mode.
Table 3.1 - O.P. Keys meaning
3.2.3 Leds
On, if the printer is powered on.
Off, if the printer is powered off.
Blinks, when the printer is in Setup Mode.
ON LINE
Lit, when the printer is on line.
Unlit, when the printer is off line.
Blinks, when the printer is receiving data from the host.
If the printer is in Setup Mode, this led indicates which setup page is selected for printing.
EJECT
STATION
1
When using the IBM 4722, IBM 9068 and the Olivetti protocols in two operators (“booking”) mode, the STATION
1 led is lit, to indicate that the corresponding settings apply.
If the printer is in Setup Mode, this led indicates which setup page is selected for printing.
Blinks, together with the other operator panel leds, if a printer error occurs. See chapter 4.8.2 for details.
STATION
2
LQ
When using the IBM 4722, IBM 9068 and the Olivetti protocols in two operators (“booking”) mode, the STATION
2 led is lit, to indicate that the corresponding settings apply.
If the printer is in Setup Mode, this led indicates which setup page is selected for printing.
Blinks, together with the other operator panel leds, if a printer error occurs. See chapter 4.8.2 for details.
Table 3.2 - O.P. Leds meaning
