Maintenance Manual SP 40
Rev. 005
57
Chapter 3
Operabilty and Configuration
EDGE DETECTION Normal*, Safe When safe is select the edge detection is always from outside to inside of the
paper.
SAFE BOTTOM EDGE No, yes When yes sets the bottom printing margin is 6.6mm instead of 2.8mm.
GET EDGE QUOTE 0/4”*, 1/4”, 2/4”, 3/4”, 4/4”, 5/4”,
6/4”, 7/4”
Sets the position in which the left paper edge is checked. If set to 0, the check
is performed at the first line. The other values correspond to the physical
distance from the first line.
PASSBOOK TYPE Setup, SW control*
Fixed thick*, Vertical, Horizontal
Sets the type of pass-book control.
If Setup if selected, printing on passbooks fixed thickness, with vertical fold,
with horizontal fold.
Table 3.3 - Configuration Form Parameters description cont'd
