Page 66
2 = Send Stay Mode arm/disarm 6 = Send all zone restores at disarm only
3 = Send disarm only after activation's 7 = Spare
4 = Send Stay Mode disarm only after alarm 8 = Spare
**Area “A” Contact ID Account Code **
P536E Account number for Area "A" - default 0000 Page 29
**Area “A” Arm/Disarm Reporting Scenario **
P537E Area A Arm/Disarm reports mapped to scenario 1-4 default 1 Page 29
**Area “A” Child Disarm Reporting Scenario **
P538E Area A Child Disarm Reporting scenario 1-4 default 1 Page 30
Enrolling Radio Detectors -Zones 1-60
P540E 1-60E Enrol Radio Detector Zones 1-60 Page 31
(If the zone Group assigned to a zone {P341-P404E} is set to a radio device type that incorporates a
tamper switch before attempting to load the radio zone , e.g. Type #5 “Crow supervised protocol” at
addresses P441-P450E, then the panel will only load on the tamper switch opening alarm transmission. If
the radio device type for the assigned group is “0” the panel will load on any transmission).
Programming Output Options
P541E-P548E OPTIONS
P541E Output #1 Primary options - Default none 1 = Invert Page 32
P542E Output #2 Primary options - Default none 2 = Flashing Page 32
P543E Output #3 Primary options - Default none 3 = Single pulse Page 32
P544E Output #4 Primary options - Default none 4 = One Shot (lock-out) Page 32
P545E Output #5 Primary options - Default none 5 = DTMF cmd remote control Page 32
P546E Output #6 Primary options - Default none 6 = Local command control Page 32
P547E Output #7 Primary options - Default none 7 = Day zone linked to pulse timer Page 32
P548E Output #8 Primary options - Default none 8 = Pulsed 24 Hour alarm Page 32
Enrolling Radio Keys
P550E 21-100E Enrol Radio Users 21-100 Page 31
(Radio Pendants can occupy User slots 21-100. If a Pendant is programmed against a User slot, that User
slot is not available as a code User).
Alarms to Output Options
P551E Output #1 Alarm options - Default 1,3,4,6 P551E-P558E OPTIONS Page 33
P552E Output #2 Alarm options - Default 1,3,4,6 1 = Keypad panic to output Page 33
P553E Output #3 Alarm options - Default 1,3,4,6 2 = Keypad fire to output Page 33
P554E Output #4 Alarm options - Default 1,3,4,6 3 = Keypad medical to output Page 33
P555E Output #5 Alarm options - Default 1,3,4,6 4 = Duress Alarm to output Page 33
P556E Output #6 Alarm options - Default 1,3,4,6 5 = Keypad tamper to output Page 33
P557E Output #7 Alarm options - Default 1,3,4,6 6 = Radio key panic to output Page 33
P558E Output #8 Alarm options - Default 1,3,4,6 7 = 24 hour alarms Page 33
8 = 24 hour fire alarms
Erasing individual Radio codes by transmitting the code
P560E Erase a Transmitted radio code from All Memory Locations Page 31
(When erase mode is started and the panel gets a code from the receiver, if that code exists in memory
and its radio device type is “0” {see P540E above}, the code will be erased from memory. If the code
found in memory has a radio device type that incorporates a tamper switch, e.g. Type #5 “Crow
supervised protocol” at addresses P441-P450E, then the panel will only erase on the tamper switch
opening alarm transmission).
Secondary Alarms to Output Options
P561E Output #1 Secondary Alarm options 2 - Default 1,2 P561E-P568E OPTIONS Page 34
P562E Output #2 Secondary Alarm options 2 - Default 1,2 1 = Zone tampers to output Page 34
P563E Output #3 Secondary Alarm options 2 - Default 1,2 2 = Cabinet tamper to output Page 34
P564E Output #4 Secondary Alarm options 2 - Default 1,2 3 = Mains fail to output Page 34
P565E Output #5 Secondary Alarm options 2 - Default 1,2 4 = Battery low to output Page 34
P566E Output #6 Secondary Alarm options 2 - Default 1,2 5 = Phone Line failure Page 34
P567E Output #7 Secondary Alarm options 2 - Default 1,2 6 = Failure to get kiss-off Page 34
P568E Output #8 Secondary Alarm options 2 - Default 1,2 7 = Automatic pulse every 5 sec. Page 34
8 = 24 Hour alarm reset pulse
