4a — MONITOR MENU
Analog 1 0.00 – 10.00 V Voltage at analog 1 (pin 24).
Analog1_Input 0 – 1023
0x3204 0x00
Analog 2 0.00 – 10.00 V Voltage at analog 2 (pin 8).
Analog2_Input 0 – 1023
0x3205 0x00
Switch 1 On / Off Switch 1 on or off (pin 24).
Sw_1 On / Off
Switches [Bit 0]
0x3226 0x00
Switch 2 On / Off Switch 2 on or off (pin 8).
Sw_2 On / Off
Switches [Bit 1]
0x3226 0x00
Switch 3 On / Off Switch 3 on or off (pin 9).
Sw_3 On / Off
Switches [Bit 2]
0x3226 0x00
Switch 4 On / Off Switch 4 on or off (pin 10).
Sw_4 On / Off
Switches [Bit 3]
0x3226 0x00
Switch 5 On / Off Switch 5 on or off (pin 11).
Sw_5 On / Off
Switches [Bit 4]
0x3226 0x00
Switch 6 On / Off Switch 6 on or off (pin 12).
Sw_6 On / Off
Switches [Bit 5]
0x3226 0x00
Switch 7 On / Off Switch 7 on or off (pin 22).
Sw_7 On / Off
Switches [Bit 6]
0x3226 0x00
Switch 8 On / Off Switch 8 on or off (pin 33).
Sw_8 On / Off
Switches [Bit 7]
0x3226 0x00
Monitor Menu: INPUTS, cont’d
DISPLAY
VARIABLE RANGE DESCRIPTION
