Installation 4
2 Installation
When you receive the Device, unpack the box to check the Device appearance and structures,
and then install SIM card and HDD according to your network situation and storage
requirement. If you need to use the audio, video, and alarm functions, get knowledge about the
connections of audio and video input and output, and alarm input and output.
Unpacking the Box 2.1
When you receive the Device, unpack the box to check the Device.
Firstly, check if there is any damage on the Device appearance (although the packing materials
are specially selected for protecting the Device from most of accidental hit during
transportation). Secondly, open the accessory box to check if the accessories are complete
against the packing list.
Instructions about front panel, rear panel, and labels:
The functions of indicator lights and ports are described in the later chapter of the Manual.
The labels on the Device are very important for our after-sales service. To ensure the
after-sales service, please keep the labels well, and do not tear or throw away. You need to
provide the serial number of the product when calling the after-sales service.
The Grand Tour 2.2
This section introduces the indicator lights and ports on the Device.
The product appearance might be different depending on the model you purchased, and the
actual product shall prevail.
2.2.1 Front Panel
Front panel Figure 2-1
Table 2-1 Indicator lights and ports description
