Troubleshooting for SkyAir Indoor Unit SiEN18-622
342 Troubleshooting
5.7 Malfunction of Capacity Setting
Remote Control
Display
AJ
Applicable
Models
FFQ, FCQ, FBQ, FHQ
Method of
Malfunction
Detection
Capacity is determined according to resistance of the capacity setting adapter and the memory
inside the IC memory on the indoor unit PCB, and whether the value is normal or abnormal is
determined.
Malfunction
Decision
Conditions
Operation and:
(1)When the capacity code is not contained in the PCB’s memory, and the capacity setting
adapter is not connected.
(2)When a capacity that doesn’t exist for that unit is set.
Supposed
Causes
Failure of capacity setting adapter connection
Failure of indoor unit PCB
Troubleshooting
Note: Capacity is factory set in the data IC on the PCB. A capacity setting adapter that matches the
capacity of the unit is required in the following case.
If the indoor PCB installed at the factory is for some reason changed at the installation site, the
capacity will not be contained in the replacement PCB.
If you connect a capacity setting adapter to a PCB in which the capacity is memorized, the
capacity setting for the PCB will become the capacity setting of the adapter. (Priority of capacity
setting adapter)
(Q0415)
NO
NO
YES
YES
Is the
capacity setting
adapter plugged into X23A
of the indoor unit
PCB?
Turn the power supply off once
and back on.
Is AJ displayed on
the remote control?
Plug a capacitor setting
adapter that matches the
capacity of the unit into
X23A. (See note)
Bad contact of capacity
setting adapter or
disconnected adapter.
Indoor
unit PCB
replacement
Could be outside cause
(noise, etc.) other than
malfunction.
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
To Next Page
