Daikin Super Multi Plus E-Series - Ceiling Mounted Cassette Type

SiEN18-622 Specifications
Specifications 31
Ceiling Mounted Cassette Type
50Hz 230V
H ( ) : dimension including control box
Model FFQ25B8V1B FFQ35B8V1B
Rated Capacity 2.5kW Class 3.5kW Class
Decoration
Panel
Color White White
Dimensions (H×W×D) 55×700×700 55×700×700
Air Flow Rates
m³/min
(cfm)
H 9.0 (318) 10.0 (353)
M— —
L 6.5 (230) 6.5 (230)
SL — —
Fan
Type Turbo Fan Turbo Fan
Motor Output W 55 55
Speed Steps 2 Steps 2 Steps
Air Direction Control Horizontal, Downward Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.37 0.40
Power Consumption (Rated) W 73 84
Power Factor % 85.8 91.3
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) H mm 260 (286)×575×575 260 (286)×575×575
Packaged Dimensions (H×W×D) mm 370×687×674 370×687×674
Weight kg 17.5 17.5
Gross Weight kg 21 21
Operation
Sound
H/L dBA 29.5/24.5 32.0/25.0
Sound Power H dBA 46.5 49.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 9.5 φ 9.5
Drain mm VP20 (O.D.
φ 26 / I.D.φ 20) VP20 (O.D.φ 26 / I.D.φ 20)
Drawing No. 3D040444A 3D040442A
Model FFQ50B8V1B FFQ60B8V1B
Rated Capacity 5.0kW Class 6.0kW Class
Decoration
Panel
Color White White
Dimensions (H×W×D) 55×700×700 55×700×700
Air Flow Rates
m³/min
(cfm)
H 12.0 (424) 15.0 (530)
M— —
L 8.0 (283) 10.0 (353)
SL — —
Fan
Type Turbo Fan Turbo Fan
Motor Output W 55 55
Speed Steps 2 Steps 2 Steps
Air Direction Control Horizontal, Downward Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.49 0.61
Power Consumption (Rated) W 97 120
Power Factor % 86.1 85.5
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) H mm 260 (286)×575×575 260 (286)×575×575
Packaged Dimensions (H×W×D) mm 370×687×674 370×687×674
Weight kg 17.5 17.5
Gross Weight kg 21 21
Operation
Sound
H/L dBA 36/27 41/32
Sound Power H dBA 53 58
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ12.7 φ12.7
Drain mm VP20 (O.D.
φ 26 / I.D.φ 20) VP20 (O.D.φ 26 / I.D.φ 20)
Drawing No. 3D040437 3D040431
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
