Specifications SiEN18-622
32 Specifications
50Hz 220-230-240V
Model FCQ35BVE FCQ50BVE
Rated Capacity 3.5kW Class 5.0kW Class
Decoration
Panel
Color White White
Dimensions (H×W×D) 40×950×950 40×950×950
Air Flow Rates
m³/min
(cfm)
H 14.0 (494) 15.0 (530)
M— —
L 10.0 (353) 11.0 (388.3)
SL — —
Fan
Type Turbo Fan Turbo Fan
Motor Output W 45 45
Speed Steps 2 Steps 2 Steps
Air Direction Control Horizontal, Downward Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Max. Rated) A 0.8 0.8
Power Consumption (Rated) W 140 140
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 230×840×840 230×840×840
Packaged Dimensions (H×W×D) mm 305×930×920 305×930×920
Weight kg 24 24
Gross Weight kg 32 32
Operation
Sound
H/L dBA 33/29 33/29
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4 (Flare)
φ
6.4 (Flare)
Gas mm
φ 9.5
(Flare)
φ 12.7
(Flare)
Drain mm VP20 (O.D.
φ 32 / I.D.φ 25) VP20 (O.D.φ 32 / I.D.φ 25)
Drawing No. 3D049093A 3D049093A
Model FCQ60BVE FCQ71BVE
Rated Capacity 6.0kW Class 7.1kW Class
Decoration
Panel
Color White White
Dimensions (H×W×D) 40×950×950 40×950×950
Air Flow Rates
m³/min
(cfm)
H 19.0 (670.7) 19.0 (670.7)
M— —
L 14.0 (494.2) 14.0 (494.2)
SL — —
Fan
Type Turbo Fan Turbo Fan
Motor Output W 45 45
Speed Steps 2 Steps 2 Steps
Air Direction Control Horizontal, Downward Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Max. Rated) A 0.8 0.8
Power Consumption (Rated) W 161 161
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 230×840×840 230×840×840
Packaged Dimensions (H×W×D) mm 305×930×920 305×930×920
Weight kg 24 24
Gross Weight kg 32 32
Operation
Sound
H/L dBA 35/30 35/30
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4 (Flare)
φ
9.5 (Flare)
Gas mm
φ12.7
(Flare)
φ15.9
(Flare)
Drain mm VP20 (O.D.
φ 32 / I.D.φ 25) VP20 (O.D.φ 32 / I.D.φ 25)
Drawing No. 3D049093A 3D049093A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
