Daikin Super Multi Plus E-Series - Ceiling Mounted Built-In Type

Printed Circuit Board Connector Wiring Diagram SiEN18-622
78 Printed Circuit Board Connector Wiring Diagram and Name
1.10 Ceiling Mounted Built-in Type
Connectors Control PCB [A1P]
Note: Other designation
Control PCB [A1P]
1) X5A Connector for terminal strip (for wired remote control)
2) X10A, X11A Connector for transformer
3) X15A Connector for float switch
4) X17A, X18A Connector for heat exchanger thermistor
5) X19A Connector for room temperature thermistor
6) X21A Connector for fan motor
7) X25A Connector for drain pump motor
8) X27A Connector for terminal strip (for inter unit wiring)
9) X33A Optional connector for wiring adapter PCB
10) X35A Optional connector for group control adapter
11) X60A, X61A Optional connector for interface adapter
1) HAP Service monitor LED
