Daikin Super Multi Plus E-Series - Indoor Unit

SiEN18-622 Instruction
System Configuration 201
FVXS 35/50 B
 Indoor Unit
 Opening the front grille
How to open the front grille:
CAUTION
• Before opening the front grille, be sure to stop the operation and turn the breaker OFF.
• Do not touch the metal parts on the inside of the indoor unit, as it may result in injury.
ON
OFF
12
4
5
2
6
7
8
3
10
14
15
12 13
Air outlet selection switch
Thissetting blowsair from upper outlet only.•
Thissetting automatically decidesablow
pattern depending on mode and conditions.
•
• The unit isshipped from the
factory with thissetting.
• Thissetting is
recommended.
Air outlet
selection
