Daikin Super Multi Plus E-Series - Ceiling Suspended Type

SiEN18-622 Specifications
Specifications 33
Ceiling Mounted Built-in Type
50Hz 220-230-240V
Ceiling Suspended Type
50Hz 220-230-240V
Model FBQ60BV1 FBQ71BV1
Rated Capacity 6.0kW Class 7.1kW Class
Decoration
Panel
Color White White
Dimensions (H×W×D) 55×1,100×500 55×1,100×500
Air Flow Rates
m³/min
(cfm)
H 17.0 (600) 19.0 (670)
M— —
L 13.0 (459) 14.0 (494)
SL — —
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 110 12.5
Speed Steps 2 steps 2 steps
Air Filter Resin Net (with mold resistant) Resin Net (with mold resistant)
Running Current (Max. Rated) A 0.9 1.1
Power Consumption (Rated) W 165 184
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 300×1,000×800 300×1,000×800
Packaged Dimensions (H×W×D) mm 400×1171×991 400×1171×991
Weight kg 41 41
Gross Weight kg 50 50
Operation
Sound
H/L dBA 41/35 41/35
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4 (Flare)
φ
9.5 (Flare)
Gas mm
φ 12.7
(Flare)
φ 15.9
(Flare)
Drain mm VP25 (O.D.
φ 32 / I.D.φ 25) VP25 (O.D.φ 32 / I.D.φ 25)
Drawing No. 3D049097 3D049097
Model FHQ35BVV1B FHQ50BVV1B FHQ60BVV1B
Rated Capacity 3.5kW Class 5.0kW Class 6.0kW Class
Decoration
Panel
Color White White White
Dimensions (H×W×D) — — —
Air Flow Rates
m³/min
(cfm)
H 13.0 (458) 13.0 (458) 17.0 (600)
M———
L 10.0 (353) 10.0 (353) 13.0 (459)
SL———
Fan
Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output W 62 62 62
Speed Steps 2 Steps 2 Steps 2 Steps
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Temperature Control Microcomputer Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 195×960×680 195×960×680 195×1,160×680
Packaged Dimensions (H×W×D) mm 279×1,046×818 279×1,046×818 279×1,246×818
Weight kg 24 25 27
Gross Weight kg 31 32 35
Operation
Sound
H/L dBA 37/32 38/33 39/33
Sound Power H/L dBA 53/48 54/49 55/49
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4 (Flare)
φ
6.4 (Flare)
φ
6.4 (Flare)
Gas mm
φ
9.5 (Flare)
φ12.7
(Flare)
φ12.7
(Flare)
Drain mm VP20 (O.D.
φ 26 / I.D.φ 20) VP20 (O.D.φ 26 / I.D.φ 20) VP20 (O.D.φ 26 / I.D.φ 20)
Drawing No. 3D037992E 3D037992E 3D037992E
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
