Instruction SiEN18-622
200 System Configuration
Remote control
1. Signal transmitter:
• It sends signals to the indoor unit.
2. Display:
• It displays the current settings. (In this
illustration, each section is shown with all its
displays ON for the purpose of explanation.)
3. HOME LEAVE button:
HOME LEAVE operation
4. POWERFUL button:
POWERFUL operation
5. TEMPERATURE adjustment buttons:
• It changes the temperature setting.
6. ON/OFF button:
• Press this button once to start operation.
Press once again to stop it.
7. MODE selector button:
• It selects the operation mode.
(AUTO/DRY/COOL/HEAT/FAN)
8. SILENT button:
OUTDOOR UNIT SILENT
operation
9. FAN setting button:
• It selects the air flow rate setting.
10. ON TIMER button
11. OFF TIMER button
12. TIMER Setting button:
• It changes the time setting.
13. TIMER CANCEL button:
• It cancels the timer setting.
14. CLOCK button
1
2
5
6
9
13
14
10
12
11
〈ARC433A7, 8〉
3
4
7
8
