SiEN18-622 Specifications
Specifications 25
50Hz 240V
50Hz 230V
Model FTKS71BVMA8
Rated Capacity 7.1kW Class
Front Panel Color White
Air Flow Rates
m³/min
(cfm)
H 16.8 (593)
M 14.2 (501)
L 11.9 (420)
SL 11.2 (394)
Fan
Type Cross Flow Fan
Motor Output W 43
Speed Steps 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof
Running Current (Rated) A 0.21
Power Consumption (Rated) W 50
Power Factor % 99.2
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366
Weight kg 12
Gross Weight kg 17
Operation
Sound
H/M/L/SL dBA 46/42/37/34
Sound Power H dBA 63
Heat Insulation Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
Gas mm
φ15.9
Drain mm
φ18.0
Drawing No. 3D047571
Model FTKS50BVMB FTKS60BVMB
Rated Capacity 5.0kW Class 6.0kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 11.4 (402) 16.2 (572)
M 9.7 (342) 13.6 (480)
L 8.0 (282) 11.4 (402)
SL 7.1 (251) 10.2 (360)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 43
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.18 0.18
Power Consumption (Rated) W 40 40
Power Factor % 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×795×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 280×840×338 337×1,147×366
Weight kg 9 12
Gross Weight kg 13 17
Operation
Sound
H/M/L/SL dBA 44/40/35/32 45/41/36/33
Sound Power H dBA 63 63
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ 6.4 φ 6.4
Gas mm φ12.7 φ12.7
Drain mm φ18.0 φ18.0
Drawing No. 3D040781A 3D040782A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
