Piping Diagrams SiEN18-622
418 Appendix
1.3.3 Floor / Ceiling Suspended Dual Type
FLXS25/35BVMA FLXS50/60BVMA
(
6.4CuT
)
(
9.5CuT
)
(
6.4CuT
)
(
9.5CuT
)
M
4D048722A
Field piping
Field piping
Sirocco flow fan
Fan motor
Thermistor
on heat
exch.
Indoor unit
Heat exchanger
Refrigerant flow
Cooling
Heating
(
6.4CuT
)
(
12.7CuT
)
(
9.5CuT
)
(
12.7CuT
)
M
4D048724A
Field piping
Field piping
Sirocco flow fan
Fan motor
Thermistor
on heat
exch.
Indoor unit
Heat exchanger
Refrigerant flow
Cooling
Heating
