Daikin Super Multi Plus E-Series - Page 432

Piping Diagrams SiEN18-622
420 Appendix
1.3.5 Ceiling Mounted Cassette Type
FFQ25/35/50/60B8V1B
FCQ35/50/60/71BVE
9.5
12.7
Outdoor unit
To
6.4
6.4
MODEL
FFQ50 · 60B8V1B
FFQ25 · 35B8V1B
Field piping φ C1220T-O
Field piping φ C1220T-O
Indoor unit
Indoor heat exchanger
C : 4D039335
Indoor heat exchanger
Field piping
Field piping
C1220T-0
C1220T-0
6.4
6.4
9.5
φ
φ
12.7
15.9
9.5
To
Outdoor unit
Indoor unit
MODEL
4D037995F
FHQ35BUV1B
FHQ35BVV1B
FCQ35BVE
FHQ50 • 60BUV1B
FHQ50 • 60BVV1B
FCQ50 • 60BVE
FBQ60BV1, FBQ60BVL
FUQ71, 100, 125BUV1B
FUQ71, 100, 125BVV1B
FHQ71, 100, 125BUV1B
FHQ71, 100, 125BVV1B
FAQ71, 100BUV1B
FAQ71, 100BVV1B
FXUQ70, 100, 125MV1
FHQ71, 100, 125BAV3B
FCQ71, 100, 125, 140DV3B
FCQ71, 100, 125, 140DAV3B
FCQ71BVE
FBQ71BV1, FBQ71BVL
