Daikin Super Multi Plus E-Series - Page 54

SiEN18-622 Specifications
Specifications 41
60Hz 220V
Model
FTXS60DVMT FTXS71DVMT
Cooling Heating Cooling Heating
Capacity 6.0kW Class 7.1kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 16.2 (572) 17.4 (614) 16.7 (590) 18.5 (653)
M 13.6 (480) 15.1 (533) 14.2 (501) 15.1 (533)
L 11.4 (402) 12.7 (448) 11.6 (409) 13.5 (477)
SL 10.2 (360) 11.4 (402) 10.6 (374) 12.1 (427)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 43 43
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current A 0.21 0.21 0.23 0.23
Power Consumption W 45 45 50 50
Power Factor % 97.4 97.4 98.8 98.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366 337×1,147×366
Weight kg 12 12
Gross Weight kg 17 17
Operation
Sound
H/M/L/SL dBA 45/41/36/33 44/40/35/32 46/42/37/34 46/42/37/34
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ12.7 φ15.9
Drain mm
φ18.0 φ18.0
Drawing No. 3D049984 3D049985
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
