SiEN18-622 Specifications
Specifications 47
Floor Standing Type
50Hz 220-230-240V / 60Hz 220-230V
Model
FVXS35BVMA FVXS50BVMA
Cooling Heating Cooling Heating
Rated Capacity 3.5kW Class 5.0kW Class
Front Panel Color Almond White Almond White
Air Flow Rates
m³/min
(cfm)
H 8.3 (293) 9.2 (325) 10.8 (381) 13.2 (466)
M 6.3 (222) 7.1 (251) 9.2 (325) 11.3 (399)
L 4.3 (152) 5.0 (177) 7.7 (272) 9.4 (332)
SL 3.4 (120) 3.6 (127) 6.7 (237) 8.3 (293)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 14+14 14+14
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Upward Right, Left, Horizontal, Upward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.16-0.15-0.14 / 0.16-0.15 0.16-0.15-0.14 / 0.16-0.15 0.27-0.26-0.25 / 0.27-0.26 0.33-0.32-0.31 / 0.33-0.32
Power Consumption (Rated) W 32 32 55 70
Power Factor % 90.9-92.8-95.2 / 90.9-92.8 90.9-92.8-95.2 / 90.9-92.8 92.6-92.0-91.7 / 92.6-92.0 96.4-95.1-94.1 / 96.4-95.1
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 600×650×195 600×650×195
Packaged Dimensions (H×W×D) mm 714×770×294 714×770×294
Weight kg 13 13
Gross Weight kg 19 19
Operation
Sound
H/M/L/SL dBA 39/33/27/24 39/33/26/23 44/40/36/33 45/40/36/33
Sound Power H dBA — — — —
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 9.5 φ12.7
Drain mm
φ20.0 φ18.0
Drawing No. 3D054434 3D055051
