SiEN18-622 Specifications
Specifications 51
Ceiling Mounted Built-in Type
50Hz 220-230-240V
60Hz 220V
Model
FBQ60BV1 FBQ71BV1
Cooling Heating Cooling Heating
Rated Capacity 6.0kW Class 7.1kW Class
Decoration
Panel
Color White White
Dimensions (H×W×D) 55×1100×500 55×1100×500
Air Flow Rates
m³/min
(cfm)
H 17.0 (600) 19.0 (670)
M— —
L 13.0 (459) 14.0 (494)
SL — —
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 110 125
Speed Steps 2 Steps 2 Steps
Air Filter Resin Net (with mold resistant) Resin Net (with mold resistant)
Running Current (Max. Rated) A 0.9 1.1
Power Consumption (Rated) W 165 145 184 164
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 300×1000×800 300×1000×800
Packaged Dimensions (H×W×D) mm 400×1171×991 400×1171×991
Weight kg 41 41
Gross Weight kg 50 50
Operation
Sound
H/L dBA 41/35 41/35
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4 (Flare)
φ
9.5 (Flare)
Gas mm
φ 12.7
(Flare)
φ 15.9
(Flare)
Drain mm VP25 (O.D.
φ 32 / I.D.φ 25) VP25 (O.D.φ 32 / I.D.φ 25)
Drawing No. 3D049097 3D049097
Model
FBQ60BVL FBQ71BVL
Cooling Heating Cooling Heating
Rated Capacity 6.0kW Class 7.1kW Class
Decoration
Panel
Color White White
Dimensions (H×W×D) 55×1100×500 55×1100×500
Air Flow Rates
m³/min
(cfm)
H 19.0 (670) 19.0 (670)
M— —
L 14.0 (494) 14.0 (494)
SL — —
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 125 125
Speed Steps 2 Steps 2 Steps
Air Filter Resin Net (with mold resistant) Resin Net (with mold resistant)
Running Current (Max. Rated) A 0.9 1.1
Power Consumption (Rated) W 165 145 184 164
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 300×1000×800 300×1000×800
Packaged Dimensions (H×W×D) mm 400×1171×991 400×1171×991
Weight kg 41 41
Gross Weight kg 50 50
Operation
Sound
H/L dBA 41/35 41/35
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4 (Flare)
φ
9.5 (Flare)
Gas mm
φ 12.7
(Flare)
φ 15.9
(Flare)
Drain mm VP25 (O.D.
φ 32 / I.D.φ 25) VP25 (O.D.φ 32 / I.D.φ 25)
Drawing No. 3D049097 3D049097
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
