SLS parameters
Value
SLS t1
5.0 s
SLS td1
0 ms
SLS td2
20 ms
SLS td3
100 ms
SLS 1 Limit
250 rpm
SLS 2 Limit
0 rpm
SLS 3 Limit
0 rpm
Table 116: Input/Output Parameters
Input/output parameters
Value
Digital Input 2
SLS 1
Digital Output 1
Group 2
Operation for Output 1
OR
Group 2 for safe digital output 1
SLS 1 Reached
Table 117: General Parameters
General parameters
Value
Drive Reset
Enabled
Drive Acknowledgment
Disabled
Table 118: SQS Parameters
SQS parameters
Value
Acknowledgment Mode (SQS)
(No effect)
SQS Type
STO
SQS Monitoring
–
SQS Ramp Monitoring
–
SQS t1
–
SQS td1
–
SQS td2
–
Table 119: Speed Measurement Configuration
Speed measurement configuration
Value
Encoder Type
Sin/Cos
Encoder power supply
15 V
Encoder reference signal
No reference signal
