Speed
Logical level
Logical level
SSR Request
SSR Reached
SQS Reached
STO Active
STO Reached
SSR Active
SQS Active
SS1 Active
SS1 Reached
SSR Max Limit
SSR Min Limit
Reset
SQS t1
Violation
t
t
t
t
t
t
t
t
t
t
t
e30bi342.10
Illustration 48: The SQS-SS1 Function as a Violation Response to an SSR Speed Violation. The SQS Function Uses Time Monitoring Mode. The
SS1 Signals are not Used with the SQS-SS1 Mode.
AQ319736045637en-000101 / DPD0179888 | Danfoss A/S © 2021.06
Safety Functions
VACON® NXP Advanced Safety Options
Operating Guide
