DC3000 USER INTERFACE
2. Enter the appropriate information in the form as described below.
Select this box to enable DHCP (Dynamic Host Configuration
Protocol.) If selected, the system gets the IP Address, Net Mask,
and Gateway IP Address from a DHCP server. When selected, the
manual entry fields for these protocols will not be available.
When Enable DHCP is not selected, you must specify unique IP
Address information.
An IP address specifies a unique host ID for the controller on a
particular TCP/IP network. Consult your network administrator for a
valid IP address for the reader.
NOTE: If you choose to enable a second IP
address, the local IP address must be entered in
the IP Address 1 text fields. The Host IP address
must then be entered in the IP Address 2 text
fields. This is because the Gateway Address is
associated with IP address 2.
A net mask modifies a standard IP address into subnets. A default
net mask should be valid in most cases (255.255.255.0). Consult
your network administrator for the net mask value.
A gateway allows the reader to reach other systems not on the local
network and remote systems to reach the reader. If the reader
requires external connectivity, consult your network administrator for
a valid gateway address.
Enter a secondary IP address for the unit.
NOTE: If you choose to enable a second IP
address, the local IP address must be entered in
the IP Address 1 text fields. The Host IP address
must then be entered in the IP Address 2 text
fields. This is because the Gateway Address is
associated with IP address 2.
Enter a secondary Net Mask for the unit.
