Select the check box to enable. When checked, a Separator text field is
revealed. Enter a separator character in the text field provided. Alibi
storage information is appended after the separator. This is a MAC
address, followed by a 10 digit sequence number, dash, then 14 char
date/time.
Format: 00:0e:13:05:00:01nnnnnnnnnn-YYYYMMDDhhmmss
NOTE: Alibi is only available for controller
model DC3000-1200 (OIML) and
dimensioner model DM3610-3200 (OIML).
Select the check box to enable. When checked, Volume Units, Volume
Field Width, and Volume Precision drop-down boxes are revealed.
Select cubic Volume Units from the drop-down list. Selections include in³
(inches cubed), ft³ (feet cubed), cm³ (centimeters cubed), and dm³
(decimeters cubed).
Select a Volume Field Width of 2 to 8 from the drop-down list. This
represents the number of characters available for the field width. If the
value has fewer characters than the field width, it will be padded with
zeros on the left.
Select a Volume Precision of 0 to 3 from the drop-down list. This is the
number of digits appearing after the decimal point.
For example:
If Volume Precision is set at 1 (1 decimal place), Volume Field
Width is set at 5, and the volume is 25.8 cm³, then the returned
value in the host message will be 025.8
If Volume Precision is set at 2 (2 decimal place), Volume Field
Width is set at 8, and the volume is 25.8 cm³, then the returned
value in the host message will be 00025.80
Enter a heart beat message in milliseconds if desired. If no other message
is sent for the time period specified in Heart Beat Time Out, the specified
heart beat message string is sent.
