Field Name
Action/Definition
Field Width
Select the field width of the minimal number of characters for length,
width, and height from the drop-down list. 2 to 7 characters are available.
If the value has fewer characters than the field width, it will be padded with
zeros on the left.
For example:
If Precision is set at 1 (1 decimal place), field width is set at 5, and
the dimension is 12.3, then the returned value in the host message
will be 012.3
If Precision is set at 2 (2 decimal place), field width is set at 7, and
the dimension is 12.3, then the returned value in the host message
will be 0012.30
Dimension
Units
Select in (inches), mm (millimeters), or cm (centimeters) from the drop
down list.
Precision
Select 0, 1, or 2 from the drop-down list. This is the number of digits
appearing after the decimal point.
Field Delimiter
Enter a character to be used as a delimiter between length, width, and
height fields. A semicolon is often used to separate data.
Omit Decimal
Select this check box to remove the decimal point character from the
message. Only the decimal point character is removed, and digits before
and after the decimal point remain.
Lead Padding
Enter characters to proceed the length, width, and height field.
Trail Padding
Enter characters to follow the length, width, and height field.
Append Units
Select the check box to enable. When checked, a Separator text field is
revealed. Enter a separator character in the text field provided. A unit
abbreviation (mm, cm, or in) will be appended after the separator.
Append
Ready Status
Select the check box to enable. When checked, a Separator text field is
revealed. Enter a separator character in the text field provided.
NOTREADY or READY will be appended after the separator. NOTREADY
indicates that this package result is not legal-for-trade.
Append NoDim
Status
Select the check box to enable. When checked, a Separator text field is
revealed. Enter a separator character in the text field provided. If the
package is a NoDim, a reason code is appended after the separator.
For example:
NODIM_BOX_STACKED, NODIM_BOX_SIDES_TO_NOISY
A NoDim reason indicates that this package result is not legal-for-trade.
