DS6300 REFERENCE MANUAL
30
3
INPUT 2 (ENCODER) CONNECTIONS USING DS6300 POWER
(red)
(whi te)
OEK-1 Encoder (PNP)
(black)
Figure 36 - OEK-1 Encoder PNP Using DS6300 Power
Power to Input
Input Device Signal
Input Device
Reference
In put De vi ce (Enc ode r)
Figure 37 - Encoder NPN Using DS6300 Power
INPUT 2 (ENCODER) CONNECTIONS USING EXTERNAL POWER
External Device
Ground Reference
Input
Sign al
Figure 38 - PNP Encoder Using External Power (i.e. PLC signal)
External Device
Power Reference
Input
Signal
Figure 39 - NPN Encoder Using External Power (i.e. PLC signal)
