ABC Codabar

The following options apply to the ABC Codabar symbology.

ABC Codabar Enable/Disable

Enables/Disables ability of reader to decode ABC Codabar labels.

ABC Codabar Concatenation Mode

Specifies the concatenation mode between Static and Dynamic.

$CCBAB00

ABC Codabar = Disable

$CCBAB01

ABC Codabar = Enable

DEFAULT

$CCBCM00

ABC Codabar Concatenation Mode = Static

$CCBCM01

ABC Codabar Concatenation Mode = Dynamic

DEFAULT
