LED and Beeper Indications
Product Reference Guide
313
Programming Mode
The following indications ONLY occur when the reader is in Programming Mode:
Error Codes
Upon startup, if the reader sounds a long tone, this means the reader has not
passed its automatic Selftest and has entered FRU (Field Replaceable Unit) iso-
lation mode. If the reader is reset, the sequence will be repeated. The following
table describes the LED flashes/beep codes associated with an error found.
INDICATION DESCRIPTION LED BEEPER
Label Program-
ming Mode
Entry
A valid programming label has
been scanned.
LED blinks continuously
Reader sounds four low fre-
quency beeps.
Label Program-
ming Mode
Rejection of
Label
A label has been rejected. N/A
Reader sounds three times at
lowest frequency & current
volume.
Label Program-
ming Mode
Acceptance of
Partial Label
In cases where multiple labels
must be scanned to program
one feature, this indication
acknowledges each portion as
it is successfully scanned.
N/A
Reader sounds one short beep
at highest frequency & current
volume.
Label Program-
ming Mode
Acceptance of
Programming
Configuration option(s) have
been successfully pro-
grammed via labels and the
reader has exited Program-
ming Mode.
N/A
Reader sounds one high fre-
quency beep and four low fre-
quency beeps followed by
reset beeps.
Label Program-
ming Mode Can-
cel Item Entry
Cancel label has been scanned. N/A
Reader sounds two times at
low frequency and current vol-
ume.
NUMBER OF LED
FLASHES/BEEPS
ERROR CORRECTIVE ACTION
1 Configuration
Contact Helpdesk for assis-
tance
2 Interface PCB
4 Reader Module
5 [Reserved]
6 Digital PCB
14 CPLD/Code Mismatch
To Next Page
