Enter/Exit Programming Mode
268 QuickScan™ I QM21X1 / QBT21X1
BT SECURITY FEATURES
On the BT system, it is possible to set a (configurable) PIN code to authenticate/
connect BT devices, and encrypt the data.
The BT PIN code can be enabled and configured by reading the bar codes in the
following sections.
Follow these steps to set the PIN code for a scanner:
1. Enable BT Security Mode by scanning the “Enable” bar code below.
2. Select a PIN code length of either 4 or 16 characters by scanning the
appropriate bar code in "Select PIN Code Length" on page 269.
3. Scan the relevant bar code from "Set PIN Code" on page 269, then scan the
desired alphanumeric characters from the keypad in Appendix D, Keypad
to set the PIN code.
See page 308
in “References” for more detailed information and examples for
this feature.
BT Security Mode
This feature enables/disables authentication and encryption of the BT link. Use
the feature "BT Pin Code" on page 269 to specify the PIN code used to authenti-
cate the BT Link.
NOTE
If you are using a BT scanner directly connected to a host through a BT dongle, verify that
the scanner and the BT driver used by the dongle share the same PIN code and the same
security level. Otherwise the connection cannot be established.
NOTE
Changing the security mode setting will unlink the devices. If the
Automatic Configuration Update is set to the default “Enabled” set-
ting, the devices must only be relinked. If the Automatic Configuration
Update is set to “Disabled,” the Security Mode setting must also be
updated in the Base Station using Aladdin. After the Base Station has
been updated, the devices must be relinked.
BT Security Mode = Disable
BT Security Mode = Enable
DEFAULT
