Chapter 6 Description of Operations
PAGE 6-33
1.If the rate start torque (angle) cannot be detected during the fastening operation, the
rate check will not be performed.
2.Under the following conditions, the torque (angle) at the end of fastening is judged as
the rate end torque (angle).
•If the set values are set so that rate start torque (angle) > rate end torque (angle).
•If the rate end torque (angle) cannot be detected during the fastening operation.
3. When the increase angle from the measurement start point to the end point of the rate
is 0,The operation varies depending on the software version.
·Before V1.304: The result of rate becomes "0", and rate judgment is not executed
·V1.305 or later: The result of the rate becomes the maximum and the rate judgment
is rate high NG
●FUSION/HFC3000 Fastening Parameter (Rate) Correspondence Table
FUSION
Fastening Parameter
HFC3000
Fastening Parameter
Function
17 Threshold Torque
112 Rate 1 Start Torque
The torque value at the start point of
measurement of torque rate 1 is set.
15 1st Torque
(1st Rate End Torque)
113 Rate 1 End Torque
The torque value at the end point of
measurement of torque rate 1 is set.
1E 2nd Rate Start Torque
114 Rate 2 Start Torque
The torque value at the start point of
measurement of torque rate 2 is set.
18 CROS Torque
(2nd Rate End Torque • 3rd
Rate End Torque)
115 Rate 2 End Torque
The torque value at the end point of
measurement of torque rate 2 is set.
116 Rate 3 Start Torque
The torque value at the start point of
measurement of torque rate 3 is set.
13 Standard Torque
(3rd Rate End Torque)
117 Rate 3 End Torque
The torque value at the end point of
measurement of torque rate 3 is set.
208 Rate 1 Start Angle
The angle value at the start point of
measurement of torque rate 1 is set.
23 1st Angle
(1st Rate End Angle)
209 Rate 1 End Angle
The angle value at the end point of
measurement of torque rate 1 is set.
26 2nd Rate Start Angle
210 Rate 2 Start Angle
The angle value at the start point of
measurement of torque rate 2 is set.
24 CROS Angle
(2nd Rate End Angle • 3rd
Rate Start Angle)
211 Rate 2 End Angle
The angle value at the end point of
measurement of torque rate 2 is set.
212 Rate 3 Start Angle
The angle value at the start point of
measurement of torque rate 3 is set.
27 3rd Rate Start Angle
22 Standard Angle
(3rd Rate End Angle)
213 Rate 3 End Angle
The angle value at the end point of
measurement of torque rate 3 is set.
Caution
