Chapter 6 Description of Operations
PAGE 6-47
SYS.035 System Option 3 Standard setting: 000000
An optional function of the Unit is set here.
*****1: Prohibition of Resume after Total Accept Relay (0: OFF./1: ON).
・Set to “1” if restart is to be prohibited when the TOTAL-OK state is entered.
Even if Spindle judgment is REJECT (NG), the next fastening start can not be
performed before the Controller software version 1.300.
In order to release the fastening operation, please turn ON any of the following input
signals.
RESET
STOP
PROGRAM
* Even if the PLC I/O input signal [BATCH OK RESET] is turned "ON", the fastening
operation can not be banned.
****1*：Initial Positon of Fastening Result Mode (0:D-No.00/1:D-No.37)
When the controller is started, set the initial position of the fastening result mode.
・0: D-No.00 Peak Torque
・1: D-No.37 Peak torque (upper part) / Final angle (lower part)
***1**：Display Stop Status (0:During Stop Input/1:Only Startup)
Change the condition to display the STOP status of the controller.
• 0: While the PLC I / O input signal [STOP] is "ON"
• 1:While the PLC I / O input signal [STOP] is "ON" and the rising edge of the PLC I/O
output signal [START (REVERSE)] ("OFF" → "ON")
**1***：CW/CCW Change Select (0:PLC input Signal/1: CW/CCW switch)
Sets the operation when the IO input signal “START” turns ON by switching the Normal
/Reverse changeover switch of the tool to the reverse rotation mode.
・0: Starts the fastening operation.
・1: Starts the reverse rotation operation.
*1****：Unused
Please use 0.
1*****：Special Function 1(0:OFF/1:ON)
Please use 0.
SYS.036 Gearhead Option Standard setting: 0, Setting range: 0 ~ 2
0: Standard head/1: Regular tube nut/2: Inverted tube nut
SYS.037 Ordinary Starting Switch Level Standard setting: 10, Setting range: 0 ~ 255
Please set 10.
SYS.038 High-speed Starting Switch Level Standard setting: 40, Setting range: 0 ~ 255
Please set 40.
*Please set 10 for the tool of D type.
SYS.039 Reversing Switch Level Standard setting: 10, Setting range: 0 ~ 255
Please set 10.
SYS.040~049 For Adjustment by the Manufacturer
Not used.
S0140185-H
