Chapter 6 Description of Operations
PAGE 6-50
(5) Option Information 1
SYS.300 Connected Fieldbus Information
The type of fieldbus installed on the fieldbus port is indicated.
SYS.301 ANYBUS-CC Version (besides standard IO)
The ANYBUS-CC version of the fieldbus port is indicated.
SYS.302 Unit Setting Fieldbus Information
The type of fieldbus set in the Unit is indicated.
Fieldbus unset (Standard IO)
MFC-CC Installed
(CC-Link)
MFC-DN
Installed
(DeviceNet)
MFC-PB Installed
(PROFIBUS
DP-V1)
MFC-PN Installed
(PROFINET IO)
MFC-EN Installed
(EtherNet/IP)
S0140185-H
To Next Page
