Chapter 6 Description of Operations
PAGE 6-51
SYS.300
CC-Link
DeviceNet
PROFIBUS
DP-V1
PROFINET
IO
EtherNet/IP
SYS.303
○
○
○
-
-
SYS.304
○
○
-
-
-
SYS.305
○
-
-
-
-
SYS.306
○
-
-
-
-
SYS.307
○
○
○
○
○
SYS.308
○
○
○
○
○
SYS.309
○
○
○
○
○
SYS.310
○
○
○
○
○
SYS.311
○
○
○
○
○
SYS.312
-
-
-
○
○
SYS.313
-
-
-
○
○
SYS.314
-
-
-
○
○
SYS.315
-
-
-
○
○
SYS.316
-
-
-
○
○
SYS.317
-
-
-
○
○
SYS.303 Station No. (Node Address) (CC-Link, DeviceNet, PROFIBUSDP-V1)
The station No. (node address) of the fieldbus set in the Unit is indicated.
Fieldbus Type
CC-Link
DeviceNet
PROFIBUSDP-V1
1～64
0～63
0～125
SYS.304 Communication Speed Setting range: 0 ~ 4 (CC-Link, DeviceNet)
The communication speed of the fieldbus set in the Unit is indicated.
Fieldbus Type
System Parameter D-No.304
0
1
2
3
4
CC-Link
156kbps
625kbps
2.5Mbps
5Mbps
10Mbps
DeviceNet
125kbps
250kbps
500kbps
-
-
SYS.305 Occupied Stations Setting range: 1 ~ 4 (CC-Link)
The number of occupied stations of the fieldbus set in the Unit is indicated.
SYS.306 Extended Cyclic Setting Setting range: 1, 2, 4, 8 (CC-Link)
The extended cyclic setting of the fieldbus set in the Unit is indicated.
SYS.307 I/O Setting Byte Length “PLC ￫ Master Spindle” [byte]
(besides standard IO)
The I/O setting byte length for “PLC ￫ MASTER Spindle” of the fieldbus set in the Unit is indicated.
SYS.308 I/O Setting Byte Length “Master Spindle ￫ PLC” [byte]
(besides standard IO)
The I/O setting byte length for “MASTER Spindle ￫ PLC” of the fieldbus set in the Unit is indicated.
S0140185-H
