Chapter 6 Description of Operations
PAGE 6-52
SYS.309 Message Block Byte Length [byte] (besides standard IO)
The message block byte length of the fieldbus set in the Unit is indicated.
Fieldbus type
CC-Link
DeviceNet
PROFIBUSDP-V1
PROFINET IO
EtherNet/IP
144byte
250 byte
64 byte
250 byte
250 byte
SYS.310 Message Setting Byte Length “PLC ￫ Master Spindle” [byte]
(besides standard IO)
The message setting byte length for “PLC ￫ MASTER Spindle” of the fieldbus set in the Unit is
indicated.
SYS.311 Message Setting Byte Length “Master Spindle ￫ PLC” [byte]
(besides standard IO)
The message setting byte length for “MASTER Spindle ￫ PLC” of the fieldbus set in the Unit is
indicated.
SYS.312 IP Address (upper 6 digits) SYS.313 IP Address (lower 6 digits)
Setting range: 0 ~ 255 (PROFINET IO, EtherNet/IP)
The IP address of the fieldbus set in the Unit is indicated.
SYS.314 Subnet Mask (upper 6 digits) SYS.315 Subnet Mask (lower 6 digits)
Setting range: 0 ~ 255 (PROFINET IO, EtherNet/IP)
The subnet mask of the fieldbus set in the Unit is indicated.
SYS.316 Gateway (upper 6 digits) SYS.317 Gateway (lower 6 digits)
Setting range: 0 ~ 255 (PROFINET IO, EtherNet/IP)
The gateway of the fieldbus set in the Unit is indicated.
S0140185-H
