Chapter 6 Description of Operations
PAGE 6-79
(Continuation from previous page)
D-No.562 CW Swing Stop Servo Lock Time [msec] Initial value: 5
D-No.572 CCW Swing Stop Servo Lock Time [msec] Initial value: 5
Setting range: 0~200
When the tool is shaken and the fastening is paused, a servo lock is applied for the set amount of
time to relax the stop shock.
D-No.563 CW Swing Motor Resume Dwell Time [msec] Initial value: 15
D-No.573 CCW Swing Motor Resume Dwell Time [msec] Initial value: 15
Setting range: 0~200
The time until rotation is started again from the point at which fastening is paused is set.
Ordinarily, this is set to be longer than the Servo Lock Time (however, use is possible even if Servo
Lock Time > Gyro Pause Restart Time).
When the set time is increased, the fastening time is increased correspondingly.
S0140185-H
