Chapter 4 Installation
PAGE 4-15
BATCH OK RESET: BATCH COUNTER RESET SIGNAL PIN No.: TB3-5
When a change of WORK has been selected at the terminal block, the current cycle count value is
cleared by input of this reset signal.
When a change of WORK has been selected at the Unit indicator panel, the current cycle count value
is cleared by input of this reset signal. Or, after performing fastening for the set number of times, the
cycle count value is cleared automatically at the start of the next fastening process.
BANK SELECT: OUTPUT SIGNAL BANK SELECT SIGNAL PIN No.: TB1-12
The contents of the eight output signals are changed by switching ON/OFF the BANK SELECT signal.
UNUSED PIN No.: TB3-6
Not connected internally
ID SELECT ENABLE：ID SELECT ENABLE SIGNAL PIN No.: TB3-10
System parameter: D - No 411 "External Input Select" with "External Input Select" set to "ID Input",
the ID selection setting becomes enable by setting this signal to “ON”.
The WORK number can be selected by the input ID code (ASCII character · maximum 32 characters)
Also, if the external input selection is "Input ID" and this signal is "OFF", select the WORK number
from the PLC.
External input Select is set with UserConsole "Graphic style parameter setup (System parameter)".
This signal can be used with Controller software version V1.301 or later.
S0140185-H
