WORK OUTPUT 0 ~ 5: WORK SELECTION INPUT CHECK
The input signals, WORK SELECT 0 ~ 5, are returned as they are as the output signals, WORK
OUTPUT 0 ~ 5.
These are used to confirm matching with the work selection that is input.
WORK
OUTPUT 5
PIN No.：TB2-1
WORK
OUTPUT 4
PIN No.: TB2-6
WORK
OUTPUT 3
PIN No.：TB3-8
WORK
OUTPUT 2
PIN No.：TB3-7
WORK
OUTPUT 1
PIN No.：TB2-5
WORK
OUTPUT 0
PIN No.：TB2-4
WORK
No.
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
1
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
ON
2
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
ON
OFF(OPEN)
3
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
ON
ON
4
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
ON
OFF(OPEN)
OFF(OPEN)
5
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
ON
OFF(OPEN)
ON
6
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
ON
ON
OFF(OPEN)
7
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
ON
ON
ON
8
OFF(OPEN)
OFF(OPEN)
ON
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
9
OFF(OPEN)
OFF(OPEN)
ON
OFF(OPEN)
OFF(OPEN)
ON
10
OFF(OPEN)
OFF(OPEN)
ON
OFF(OPEN)
ON
OFF(OPEN)
11
OFF(OPEN)
OFF(OPEN)
ON
OFF(OPEN)
ON
ON
12
OFF(OPEN)
OFF(OPEN)
ON
ON
OFF(OPEN)
OFF(OPEN)
13
OFF(OPEN)
OFF(OPEN)
ON
ON
OFF(OPEN)
ON
14
OFF(OPEN)
OFF(OPEN)
ON
ON
ON
OFF(OPEN)
15
OFF(OPEN)
OFF(OPEN)
ON
ON
ON
ON
16
OFF(OPEN)
ON
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
17
OFF(OPEN)
ON
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
ON
18
OFF(OPEN)
ON
OFF(OPEN)
OFF(OPEN)
ON
OFF(OPEN)
19
OFF(OPEN)
ON
OFF(OPEN)
OFF(OPEN)
ON
ON
20
OFF(OPEN)
ON
OFF(OPEN)
ON
OFF(OPEN)
OFF(OPEN)
21
OFF(OPEN)
ON
OFF(OPEN)
ON
OFF(OPEN)
ON
22
OFF(OPEN)
ON
OFF(OPEN)
ON
ON
OFF(OPEN)
23
OFF(OPEN)
ON
OFF(OPEN)
ON
ON
ON
24
OFF(OPEN)
ON
ON
OFF(OPEN)
OFF(OPEN)
OFF(OPEN)
25
OFF(OPEN)
ON
ON
OFF(OPEN)
OFF(OPEN)
ON
26
OFF(OPEN)
ON
ON
OFF(OPEN)
ON
OFF(OPEN)
27
OFF(OPEN)
ON
ON
OFF(OPEN)
ON
ON
28
OFF(OPEN)
ON
ON
ON
OFF(OPEN)
OFF(OPEN)
29
OFF(OPEN)
ON
ON
ON
OFF(OPEN)
ON
30
OFF(OPEN)
ON
ON
ON
ON
OFF(OPEN)
31
OFF(OPEN)
ON
ON
ON
ON
ON
32
