Chapter 6 Description of Operations
PAGE 6-12
●List of Contents Indicated in the Fastening Result Mode(1/2)
If a value exceeding (falling below) the upper and lower limits of the tightening parameter is
detected during the tightening operation,
The DATA display section of COUNT / D - No. 00 to 10 switches the display of the following items and
1STNG items every second.
For details, refer to 6-7. "Fastening NG (Failure) Result Indications ".
WORK
COUNT
/D-NO
DATA
Judgment
Unit
r01
～
r64
c##
Peak torque
H/L
N • m
01
Final angle
H/L
Deg
02
Rate 1
H/L
N • m/deg
03
Rate 2
H/L
N • m/deg
04
Rate 3
H/L
N • m/deg
05
1st time
H/L
Sec
06
2nd time
H/L
Sec
07
Cycle time
H/L
Sec
08
Differential angle
H/L
Deg
09
Spindle judgment
reject: REJECT (fastening NG (fail))
accept: ACCEPT (fastening OK)
abn: Stoppage due to ABNORMAL (error occurrence) signal
stop: Stoppage due to STOP (emergency stop) signal
reset: System cleared by RESET signal
bypass: Stopping due to BYPASS signal
st-off: START signal set to OFF during output of BUSY (operating)
signal
10
1st NG item *The D-No. of the fastening NG (fail) item that occurred
first is indicated.
11
Rate 1/2/3 judgment
H/L
12
Fastening method … trq: torque method, ang: angle method
13
Number of fastening steps … 1 step, 2 steps, 3 steps
14
Self-checking flag (SC) … ON: self-checking performed
OFF: self-checking not performed
15
Reverse flag (RV) … ON: reverse rotation performed
OFF: reverse rotation not performed
16
Servo lock flag (SL) … ON: servo lock performed
OFF: servo lock not performed
17
1st peak torque
N • m
18
2nd peak torque
N • m
19
Snug torque
H
N • m
20
Final torque
H/L
N • m
(Continued on next page)
