Chapter 6 Description of Operations
PAGE 6-13
●List of Contents Indicated in the Fastening Result Mode(2/2)
WORK
COUNT
/D-NO
DATA
Judgment
Unit
r01
～
r64
21
Rate 1 increment torque (torque from start of rate 1 to end of rate 1)
N • m
22
Rate 1 increment angle (angle from start of rate 1 to end of rate 1)
Deg
23
Rate 2 increment torque (torque from start of rate 2 to end of rate 2)
N • m
24
Rate 2 increment angle (angle from start of rate 2 to end of rate 2)
Deg
25
Rate 3 increment torque (torque from start of rate 3 to end of rate 3)
N • m
26
Rate 3 increment angle (angle from start of rate 3 to end of rate 3)
Deg
27
Peak current (current high/low limit warning indication)
H/L
A
28
Rundown revolutions
H/L
rev.
29
Load rate
%
30
Current value at stopping of fastening
A
31
------ indication
32
Spindle cycle count (×1 million) * “--" if less than 1 million cycles
33
Spindle cycle count (×1)
34
Tool cycle count (×1 million) * “--" if less than 1 million cycles
35
Tool cycle count (×1)
36
ACCEPT COUNT *0 to cycle count (0 to 99)
This DATA indication is always performed as [c##] for COUNT/D-No.
00.
37
Peak torque (upper part)
Final angle (lower part)
S0140185-H
