Figure 133. Cable routing – 24 x 2.5 inch drive backplane with 20 SAS plus 4 PCIe and adapter PERC
1
backplane 2 backplane signal cable
3 backplane power cable A 4 backplane power cable B
5 SAS cable 6 system board
7 adapter PERC 8 PCIe card
9 PCIe cable A 10 PCIe cable B
11 backplane expander
Installing and removing system components 175
