4. Product overview
Installation and Operation Manual for RPI M50A
10
4. Product overview
4.1 Scope of delivery
Part Qty Image/Description Part Qty Image/Description
Inverter 1
DC bus bar 2 Used when the solar mod-
ules have to be grounded
and for connecting the
two DC inputs to one MPP
tracker.
Mounting plate 1 DC Fuse holder 1 Used when the solar mod-
ules have to be grounded.
AC plug 1 China Aviation Optical-
Electrical Technology Co.
PVE5T125KE36
Screw for
grounding the
inverter housing
1 An appropriate screw with
washer, washer spring
and toothed ring is already
mounted to the inverter
DC plugs 10 Multi-Contact MC4 plug for
DC+ (32.0017P0001-UR for
4/6 mm
2
)
Quick Installa-
tion Guide and
General Safety
Instructions
1
Installation and Operation Manual
RPI M50A
10 Multi-Contact MC4 plug for
DC– (32.0016P0001-UR for
4/6 mm
2
)
