5 Planning the installation
Installation and Operation Manual for RPI M50A
24
5.6 Dimensions
107
460
172.8
158.7
31
30
25
82
Fig. 5.10: Dimensions of mounting plate
612 278
740
Fig. 5.11: Dimensions of inverter
