11
Installation and Operation Manual for RPI M50A
4. Product overview
4.2 Components and connectors
1
2
3
4
5
6
No. Component / connector Description
1
Display, buttons, status LEDs See “4.3 Display, buttons, status LEDs”, p. 12
String fuses and AC/DC overvoltage protection
See “4.4 String fuses and AC/DC surge protection
device”, p. 12
3
Air inlets See “4.5 Air inlets and fans”, p. 13
4
Electrical connectors See “4.6 Electrical connectors”, p. 14
5
Fans See “4.5 Air inlets and fans”, p. 13
6
Type label See “4.7 Information on the type label”, p. 17
