5.11 What you need
Beside the parts delivered with the inverter (see “4.1 Scope of delivery”, p. 10), you may need the following
addititional parts and tools.
Part Quantity Image/Description
For mounting the inverter
M6 mounting screws 12 The mounting plate has to be mounted with 12 M6 screws.
Depending on where you mount the inverter (e. g. on a brick wall,
concrete wall, metal frame etc.) you may need additional mounting
material.
This could be:
Wall plugs, washers, washer springs, nuts etc.
For connecting the inverter to the grid (AC)
AC cable - Use properly sized wire to connect to the correct poles (see table)
AC connector
China Aviation
Optical-Electrical
Technology Co.
PVE5T125KE36
Current rating 100 A
Min. / Max. cable diameter 37 ... 44 mm
Min. / Max. wire size 25 ... 35 mm
2
Recommended torque for terminal
screws
3 Nm
AC plug delivered with the inverter can be used with exible copper
cable.
When calculating the cross section of the cable, consider:
● material used
● thermal conditions
● cable length
● type of installation
● AC voltage drop
● power losses in cable
Always follow the system installation requirements dened for your
country!
France: Follow the system installation requirements dened by UTE
15-712-1 regarding minimum cable sections and protections against
overheating due to high currents!
Germany: Follow the system installation requirements dened by VDE
0100 712 regarding minimum cable sections and protections against
overheating due to high currents!
For a description how to connect the AC cable to the AC connector
see “6.4 Connecting to the grid (AC)”, p. 40.
