Installation and Operation Manual for RPI M50A
13. Technical data
EN
13. Technical data
Input (DC) RPI M50A_120 RPI M50A_122
Maximum recommended PV power 70 kW
P
1)
Maximum input power 58 kW
Nominal power 52 kW
2)
Voltage range 200 ... 1100 V
DC
3)
MPP operating voltage range 200 ... 1000 V
DC
Maximum input voltage 1000 V
DC
Nominal voltage 600 V
DC
Startup voltage 250 V
DC
Startup power 40 W
Voltage range for maximum power 520 ... 800 V
DC
symmetrical load (50/50 %)
Maximum input current; total (DC1 / DC2) 100 A (50 A / 50 A)
Maximum current per input 10 A
Maximum short circuit current in case of a failure 60 A (12 A per string)
Number of MPP trackers
Parallel inputs: 1 MPP tracker; Separate inputs: 2 MPP
trackers
Input load ≤ 34.8 kW per MPPT, symmetrical and asymmetrical
Number of DC inputs; total (DC1 / DC 2) 10 (5 / 5)
Galvanic isolation No
Overvoltage category
4)
II
String Fuse Protection 15 A
5)
Surge Protection Devices Type 2 none
Output (AC) RPI M50A_120 RPI M50A_122
Maximum apparent power
6) 7)
55 kVA
Nominal apparent power
6)
50 kVA
Nominal voltage
8)
230 V
AC
± 20 % / 400 V
AC
± 20 %; 3 phase + PE or 3
phase + N + PE
Nominal current 73 A
Maximum current 80 A
Inrush current 200 A / 100 µs
Nominal frequency 50 / 60 Hz
Frequency range
8)
45 ... 65 Hz
Power factor adjustable 0.8 cap ... 0.8 ind
Total harmonic distortion <3%
DC Current injection <0.5% rated current
Night-time loss <2.5 W
Overvoltage category
4)
III
Surge Protection Devices Type 2 none
