11 Maintenance
Installation and Operation Manual for RPI M50A
96
11.2 Replacing the fans
1. Loosen the 4 screws of the fan section.
2. Pull out the fan section.
3. Pull out the ve connectors with the wires.
4. Plug the ve connectors with the wires into the
fan section. The order of the connectors does not
matter.
5. Put the new fan section into the inverter housing.
6. Fasten the 4 screws of the fan section.
