Starting Milling
35
Chapter 2 Milling

Orient the parts as shown in the gure, and then insert the adapter into the clamp.

Secure the adapter.
As shown in the gure, turn the xing knobs (in two locations) in the directions of the arrows while pressing in on the
adapter.
2
1
Point
If it is difcult to turn the knobs by hand, use the included wrench (for clamps).
Fixing knob
