Starting Milling
37
Chapter 2 Milling
Slide the milling bur through the milling bur holder, and determine the proper position.
Insert the milling bur as shown in the gure and make sure that both ends are within the areas of the milling bur posi-
tioner holes.
Secure the mounting screw using the hexagonal screwdriver.
Both ends of the milling bur
are within the A and B areas.
Set the milling bur in the ATC magazine.
Firmly insert it as far as possible. Up to 15 milling burs can be set. The milling bur stocker numbers are shown on the
surface of the magazine.
CAUTION
The "Cleaning" stocker is dedicated for the cleaning tool. Do not set milling burs in this stocker.
" P. 38 "STEP 4: Loading the Cleaning Tool"
