Starting Milling
41
Chapter 2 Milling
Procedure
Check the settings of the milling data.
" P. 22 "CAM Settings Necessary for Milling"
Open the [Output a le] dialog box.
In the top window of VPanel, select the machine to operate.
When multiple machines are connected, click under MACHINE
STATUS to switch between machines.
Click .
The [Open] dialog box will appear.
Select the milling data, and click "Open."
The selected milling data is displayed in the data list of the [Output a le] window.
Click [Add] in the [Output a le] window to add les when you want to output milling data continuously.
Verify that the workpiece and the milling bur are set in the milling machine.
" P. 36 "STEP 3: Loading the Milling Bur"
Click "Output."
MEMO
Changing the data list order
You can change the output order by selecting the milling data in the data list and clicking or .
(The milling data is output from the top of the data list.)
Removing milling data from the data list
To remove milling data from the output list, select the milling data in the data list and click [Remove].
Adding milling data by dragging and dropping
You can add milling data to the data list by dragging the data to the top window or the [Output a le]
window.
To Next Page
