75
CORN CRACKER INSTALLATION INSTRUCTIONS
STEP 22 - FIGURE 97
Test the machine for proper operation. Make sure the
Corn Cracker is well greased, adjusted, and that all bolts
are securely tightened.
Put guard (items 1) back in place and lock it. Install the
balancing springs (item 2) and adjust them using the
handle (item 3).
Slide the axle shaft (item 4) back in its operating position
and lock with the pin and locking pin.
NOTE: Engage the cutter head at low speed then in-
crease speed gradually, so that driving belts are
not overloaded.
3
4
2
1
5
Figure 97
Manual No. F4117E987E V1.1
