PARTIAL DISMANTLING OF THE CORN CRACKER FOR HAY CROP
STEP 1 - FIGURE 98
Slide the axle shaft outward as shown by the arrow
below.
STEP 2 - FIGURE 98
Remove the balancing springs (item 2) completely using
the handle (item 3). Open the guard (item 1).
NOTE: Grease all parts before storage. Grease all
rust-exposed components on machine.
CAUTION: Be alert when you operate and/or work
on a machine.
For hay crop, the Corn Cracker must be partially dismantled by removing the upper cracker roll. Proceed as per the
following instructions:
3
2
1
Figure 98
Manual No. F4117E987E V1.1
